my little baby Zimbraโ€ฆ

stlh smngguan tepar, PR mail server dgn spec yg di-request pak bos (postfix + LDAP + out-of-office/autoresponder/vacation feature) masih menanti… tapi syukur Alhamdulillah, kutemukan Zimbra edisi open source… lgsg aja pas hari prtama masuk kntor stlh tepar, jadi juga “My Little Baby Zimbra” ๐Ÿ˜€ kenapa kunamakan little baby? coz masih lokal-an, blum di-up-kan… ๐Ÿ˜€

sblmnya pernah bikin :

1. postfix + MYSQL + courier-imap + roundcubemail

2. postfix + LDAP + courier-imap + roundcubemail

3. postfix + LDAP + dovecot + roundcubemail

mau jalan, tapi ga punya fitur out-of-office/autoresponder/vacation… akhirnya nnya2 mbah gugel, pindahlah aku ke zimbra.

SPEC-nya AKU

1 PC server (RAM 1 GB, HDD 100 GB)

2 LAN card (1 lokal, 1 konek ke internet, ygIP lokal : 192.168.1.1)

Ubuntu Server 8.4 fresh install pke :

  • DNS server (buat domain lokal)
  • OpenSSH server (buat ngremote biar gampang)
  • hostname : mail.example.local
  • domain ntar bakal dikasih nama example.local

WARNING

sesuaikan dgn kebutuhan Anda (alokasi IP, nama domain, dll.)

– klo g salah, zimbra minta space 5 GB buat install

CUPLIKAN

1. install Ubuntu Server 8.4 dgn DNS server, OpenSSH server, dan hostname mail.example.local

2. login sbg root

3. setting SSH (biar bisa di-remote)

4. setting DNS dgn. MX record (buat deteksi mail)

# cd /etc/bind

# vim named.conf.local

zone “example.local” {

type master;

file “/etc/bind/zones/example.local.zone”;

};

zone “1.168.192.in-addr.arpa” {

type master;

file “/etc/bind/zones/rev.1.168.192.in-addr.arpa”;

};

# mkdir zones

# cd zones

# vim example.local.zone

$TTL    86400   ; 1 day

@       IN      SOA     mail.example.local. admin.mail.example.local. (

20090506; serial

7200    ; refresh (2 hours)

7200    ; retry (2 hours)

1209600 ; expire (2 weeks)

86400   ; minimum (1 day)

)

MX      10 mail     ; MTA

@       IN      NS      mail.example.local.

IN      MX      10 mail.example.local.

IN      A       192.168.1.1

www IN      A       192.168.1.1

mail  IN      A       192.168.1.1

# vim rev.1.168.192.in-addr.arpa

@       IN      SOA     mail.example.local. admin.mail.example.local. (

20090506

7200

7200

1209600

86400 )

@       IN      NS      mail.example.local.

1       IN      PTR     mail.example.local.

1       IN      PTR     example.local.

1       IN      PTR     www.example.local.

# vim /etc/resolv.conf

search example.local

nameserver 192.168.1.1

# /etc/init.d/bind9 restart

pastikan ada record MX

# dig mx example.local

5. instalasi zimbra

  • download paket zimbra untuk ubuntu, bisa di-dunlut di situs zimbra
  • yg saya pakai zcs-5.0.12_GA_2789.UBUNTU8.20090126112326.tgz, copy-kan di direktori /usr/src/

# cd /usr/src

  • install paket dependencies zimbra

# apt-get update

# apt-get upgrade

# apt-get install libpcre3 libgmp3c2 libstdc++5 libltdl3

  • untuk paket selain libstdc++5, ada di CD Ubuntu Server 8.4
  • edit file /etc/hosts, pastikan ada baris “127.0.0.1    localhost.localdomain localhost”

# vim /etc/hosts

127.0.0.1    localhost

192.168.1.1    mail.example.local mail

127.0.0.1    localhost.localdomain localhost

  • ekstrak zimbra di direktori /usr/src/

# tar -xzvf zcs-5.0.12_GA_2789.UBUNTU8.20090126112326.tgz

# mv zcs-5.0.12_GA_2789.UBUNTU8.20090126112326 zcs

# cd zcs

  • install zimbra

# ./install.sh

Operations logged to /tmp/install.log.8916
Checking for existing installation…
zimbra-ldap…NOT FOUND
zimbra-logger…NOT FOUND
zimbra-mta…NOT FOUND
zimbra-snmp…NOT FOUND
zimbra-store…NOT FOUND
zimbra-apache…NOT FOUND
zimbra-spell…NOT FOUND
zimbra-proxy…NOT FOUND
zimbra-archiving…NOT FOUND
zimbra-convertd…NOT FOUND
zimbra-cluster…NOT FOUND
zimbra-core…NOT FOUND

PLEASE READ THIS AGREEMENT CAREFULLY BEFORE USING THE SOFTWARE. ZIMBRA, INC. (“ZIMBRA”) WILL ONLY LICENSE THIS SOFTWARE TO YOU IF YOU FIRST ACCEPT THE TERMS OF THIS AGREEMENT. BY DOWNLOADING OR INSTALLING THE SOFTWARE, OR USING THE PRODUCT, YOU ARE CONSENTING TO BE BOUND BY THIS AGREEMENT. IF YOU DO NOT AGREE TO ALL OF THE TERMS OF THIS
AGREEMENT, THEN DO NOT DOWNLOAD, INSTALL OR USE THE PRODUCT.

License Terms for the Zimbra Collaboration Suite:
http://www.zimbra.com/license/zimbra_public_eula_2.1.html

Press Return to continue

Checking for prerequisites…
FOUND: NPTL
FOUND: sudo-1.6.9p10-1ubuntu3
FOUND: libidn11-1.1-1
FOUND: libpcre3-7.4-1ubuntu2
FOUND: libgmp3c2-2:4.2.2+dfsg-1ubuntu2
FOUND: libexpat1-2.0.1-0ubuntu1
FOUND: libstdc++6-4.2.3-2ubuntu7
FOUND: libstdc++5-1:3.3.6-18
FOUND: libltdl3-1.5.26-1ubuntu1
Checking for suggested prerequisites…
FOUND: perl-5.8.8
Prerequisite check complete.

Checking for installable packages

Found zimbra-core
Found zimbra-ldap
Found zimbra-logger
Found zimbra-mta
Found zimbra-snmp
Found zimbra-store
Found zimbra-apache
Found zimbra-spell
Found zimbra-proxy

Select the packages to install

Install zimbra-ldap [Y] <– enter

Install zimbra-logger [Y] <– enter

Install zimbra-mta [Y] <– enter

Install zimbra-snmp [Y] <– enter

Install zimbra-store [Y] <– enter

Install zimbra-apache [Y] <– enter

Install zimbra-spell [Y] <– enter

Install zimbra-proxy [N] <– enter
Checking required space for zimbra-core
checking space for zimbra-store

Installing:
zimbra-core
zimbra-ldap
zimbra-logger
zimbra-mta
zimbra-snmp
zimbra-store
zimbra-apache
zimbra-spell

The system will be modified.  Continue? [N] <– ketik Y, enter

Removing /opt/zimbra
Removing zimbra crontab entry…done.
done.
Cleaning up zimbra init scripts…done.
Cleaning up /etc/ld.so.conf…done.
Cleaning up /etc/security/limits.conf…done.

Finished removing Zimbra Collaboration Suite.

Installing packages

zimbra-core……zimbra-core_5.0.12_GA_2789.UBUNTU8_i386.deb…done
zimbra-ldap……zimbra-ldap_5.0.12_GA_2789.UBUNTU8_i386.deb…done
zimbra-logger……zimbra-logger_5.0.12_GA_2789.UBUNTU8_i386.deb…done
zimbra-mta……zimbra-mta_5.0.12_GA_2789.UBUNTU8_i386.deb…done
zimbra-snmp……zimbra-snmp_5.0.12_GA_2789.UBUNTU8_i386.deb…done
zimbra-store……zimbra-store_5.0.12_GA_2789.UBUNTU8_i386.deb…done
zimbra-apache……zimbra-apache_5.0.12_GA_2789.UBUNTU8_i386.deb…done
zimbra-spell……zimbra-spell_5.0.12_GA_2789.UBUNTU8_i386.deb…
Operations logged to /tmp/zmsetup.05062009-163039.log
Setting defaults…

DNS ERROR resolving MX for mail.example.local
It is suggested that the domain name have an MX record configured in DNS
Change domain name? [Yes] <– enter
Create Domain: [mail.example.local] <– ketik example.local, enter
MX: mail.example.local (192.168.1.1)

Interface: 192.168.1.1
Interface: 127.0.0.1
done.
Checking for port conflicts

Main menu

1) Common Configuration:
2) zimbra-ldap:                             Enabled
3) zimbra-store:                            Enabled
+Create Admin User:                    yes
+Admin user to create:                 [email protected]
******* +Admin Password                        UNSET
+Enable automated spam training:       yes
+Spam training user:                   [email protected]
+Non-spam(Ham) training user:          [email protected]
+Global Documents Account:             [email protected]
+SMTP host:                            mail.example.local
+Web server HTTP port:                 80
+Web server HTTPS port:                443
+Web server mode:                      http
+IMAP server port:                     143
+IMAP server SSL port:                 993
+POP server port:                      110
+POP server SSL port:                  995
+Use spell check server:               yes
+Spell server URL:
+Configure store for use with reverse mail proxy: FALSE
+Configure store for use with reverse web proxy: FALSE

4) zimbra-mta:                              Enabled
5) zimbra-snmp:                             Enabled
6) zimbra-logger:                           Enabled
7) zimbra-spell:                            Enabled
8. Default Class of Service Configuration:
r) Start servers after configuration        yes
s) Save config to file
x) Expand menu
q) Quit

Address unconfigured (**) items  (? – help) <– ketik 3, enter

Store configuration

1) Status:                                  Enabled
2) Create Admin User:                       yes
3) Admin user to create:                    [email protected]
** 4) Admin Password                           UNSET
5) Enable automated spam training:          yes
6) Spam training user:                      [email protected]
7) Non-spam(Ham) training user:             [email protected]
8. Global Documents Account:                [email protected]
9) SMTP host:                               mail.example.local
10) Web server HTTP port:                    80
11) Web server HTTPS port:                   443
12) Web server mode:                         http
13) IMAP server port:                        143
14) IMAP server SSL port:                    993
15) POP server port:                         110
16) POP server SSL port:                     995
17) Use spell check server:                  yes
18) Spell server URL:
19) Configure store for use with reverse mail proxy: FALSE
20) Configure store for use with reverse web proxy: FALSE

Select, or ‘r’ for previous menu [r] <– ketik 4, enter

Password for [email protected] (min 6 characters): [JXQyg8r2] <– masukkan password untuk admin (min. 6 karakter –> misal XXXXXXXX), enter

Store configuration

1) Status:                                  Enabled
2) Create Admin User:                       yes
3) Admin user to create:                    [email protected]
4) Admin Password                           set
5) Enable automated spam training:          yes
6) Spam training user:                      [email protected]
7) Non-spam(Ham) training user:             [email protected]
8. Global Documents Account:                [email protected]
9) SMTP host:                               mail.example.local
10) Web server HTTP port:                    80
11) Web server HTTPS port:                   443
12) Web server mode:                         http
13) IMAP server port:                        143
14) IMAP server SSL port:                    993
15) POP server port:                         110
16) POP server SSL port:                     995
17) Use spell check server:                  yes
18) Spell server URL:
19) Configure store for use with reverse mail proxy: FALSE
20) Configure store for use with reverse web proxy: FALSE

Select, or ‘r’ for previous menu [r] <– ketik r, enter

Main menu

1) Common Configuration:
2) zimbra-ldap:                             Enabled
3) zimbra-store:                            Enabled
4) zimbra-mta:                              Enabled
5) zimbra-snmp:                             Enabled
6) zimbra-logger:                           Enabled
7) zimbra-spell:                            Enabled
8. Default Class of Service Configuration:
r) Start servers after configuration        yes
s) Save config to file
x) Expand menu
q) Quit

*** CONFIGURATION COMPLETE – press ‘a’ to apply
Select from menu, or press ‘a’ to apply config (? – help) <– ketik a, enter
Save configuration data to a file? [Yes] <– enter
Save config in file: [/opt/zimbra/config.16991] <– enter
Saving config in /opt/zimbra/config.16991…done.
The system will be modified – continue? [No] <– ketik Y, enter
Operations logged to /tmp/zmsetup.05062009-163039.log
Setting local config values…

…………………………….. (ikuti sampai selesai)

6. login sbg admin, buka browser, arahkan ke atau

username : [email protected]

password : XXXXXXXX

7. login sbg user (buat dlu account-nya di hlmn admin), buka browser, arahkan ke atau

8. hepi mailing… ๐Ÿ˜€

oiya, zimbra ini jga bisa kog disetting autentikasinya pke LDAP dari mesin lain (external LDAP)…

trus, klo mo uninstall, tinggal ketik aja perintah berikut :

# cd /usr/src/zcs/

# ./install.sh -u

14 comments

    • ningnong - Reply

      klo mumet yg bginian sie, masih asikkk (drpd programming –> my head is spinning around 7 times)… ohhhhhhh…
      hehehe…

  1. mbak_cute - Reply

    go…zimbra..go..go…go….

    cepet gede ya baby zimbra…. ๐Ÿ˜€

    • ningnong - Reply

      yuhhhhuuu… our little baby zimbra is gonna be up soon…
      amien, ya mba aL… wlo install uninstall install uninstall install lagi…
      hyahahaha… ๐Ÿ˜€

  2. yusuv - Reply

    wah.. bole juga ni di coba…
    tp lebih asyik klo tutorial nya lengkap ma posfix nya.. ๐Ÿ˜€

    • ningnong - Reply

      postfix yg mana neh cup??? klo zimbra emg pke postfix kog… hehehe…
      klo yg postfix + MySQL/LDAP + roundcube + courier/dovecot klo mau tutornya, imel aja ke t4ku… ๐Ÿ˜€ cuman aku blm nglengkpin tutor bgn LDAP-nya je…

      pokoknya referensi utama ke http://flurdy.com/docs/postfix/

  3. bay-kun - Reply

    mbak ning, zimbra disini sama aplikasi desktop zimbra idem gak yak?
    soalnya pernah dapet aplikasi zimbra buat email…

    • ningnong - Reply

      tiyok tiyok.. vakasiku dums…
      hehehe ๐Ÿ˜€
      nganu, klo g salah zimbra desktop itu aplikasi yg kegunaannya mirip2 outlook gtu…
      klo yg aku pke ZCS (Zimbra Collaboration Suite) itu server zimbra nya + webmail (admin & user)… bgtulah

      utk tahu zimbra desktop lebih lngkpnya, silakan klik link berikut

    • ningnong - Reply

      hehehe, itu adalah dolananku…
      har, km kmn aja sie? kerjakan TA-mu nak…
      wkwkwk. kamu sie i’m going home mulu… aku nyanyiin lho lagunya ntar…
      salam bwt si alex, makanya mandi kamu, kan kabur jadinya si alex… ๐Ÿ˜€

  4. jose - Reply

    wah gimana nih..aku punya kendala ketika aku panggil “https://mydomain:7071/” kok gak bisa ya. dimana itu letak kesalahannya ya. mohon bantuannya. thanks

    • ningnong - Reply

      gag bisa-nya dmn yah?? ada pesan error apakah? mungkin ada servis zimbra nya yg belum up.. bisa diliat log nya dulu?

Leave Comment

Your email address will not be published. Required fields are marked *
